> FIXEDTOURECHAF FOOT
Description
Code Weight
Fixed foot
011192-2 3.3
1
2
3
4
5
31
> DIAGONAL BRACE
Dimension Diagonal
Code Weight
H 0.50 x L 1.00 1.04 m 295010-3 2.9
H 0.50 x L 1.50 1.49 m 295015-2 3.7
H 1.00 x L 0.70 1.17 m 251007-1 3.1
H 1.00 x L 1.00 1.35 m 251010-5 3.8
H 1.00 x L 1.50 1.72 m 251015-4 4.3
H 1.00 x L 2.00 2.15 m 251020-4 5.7
H 1.00 x L 2.50 2.60 m 251025-3 6.5
H 2.00 x L 0.70 2.09 m 252007-0 5.5
H 2.00 x L 1.00 2.19 m 252010-4 5.6
H 2.00 x L 1.50 2.45 m 252015-3 6.3
H 2.00 x L 2.00 2.76 m 252020-3 7.2
H 2.00 x L 2.50 3.13 m 252025-2 7.3
H 2.00 x L 3.00 3.53 m 252030-2 9.2
L Length
of ledger
H Height
between ledgers
Diagonal
> GROUTING GUARDRAIL
Dimensions
Code Weight
1.00 m
011110-4 12.0
1.50 m
011115-3 13.9
58 cm
adjustment
60 cm
adjustment
20.5 cm
adjustment
90
15
1
2
3
> SIDE BRACKET
Description
Code Weight
0.38 m bracket
011152-6 4.4
1.00 m bracket
250710-1 8.0
Sliding foot
250000-7 2.2
38
25
82.3
100
100 to 300
25
or 30
100
152
185
50
110
15
100 to 300
> STEEL TOE BOARD
Dimensions
Code Weight
1.00 m
023720-6 1.6
1.50 m
023721-4 2.4
2.00 m
023722-2 3.7
2.50 m
023723-0 4.6
3.00 m
023724-8 5.6
> ADJUSTABLE TOWER TROLLEY
Description
Code Weight
Adjustable tower trolley 011167-4 106.0
> TOURECHAF CASTORWHEEL
Description
Code Weight
Castor wheel (+ connector) 011190-6 8.5
> “U” 1 STIRRUP
Description
Code Weight
“U” 1 Stirrup
251001-4 0.75
100
Adjustable
height
4
5
9.7
33.8
98.2
8,2
19
19
100
217
50
24.3
39.3
130 at min.
> TOURECHAF CONNECTOR
Description
Code Weight
Connector
011169-0 1.8
TOURECHAF
> STEEL DECKING PANEL
Dimensions
Code Weight
1.00 x 0.20 m
110021-3 7.9
1.50 x 0.20 m
115021-8 9.2
1.00 x 0.25 m
025602-4 4.7
1.50 x 0.25 m
023621-6 7.2
2.00 x 0.25 m
023624-0 9.2
2.50 x 0.25 m
023625-7 14.8
3.00 x 0.25 m
023626-5 17.0
1.00 x 0.30 m
023684-4 5.0
1.50 x 0.30 m
023680-2 8.0
2.00 x 0.30 m
023681-0 10.5
2.50 x 0.30 m
023682-8 16.7
3.00 x 0.30 m
023683-6 19.5
> LOCKING PIN
(
FOR STANDARD
)
Description
Code Weight
Locking pin
021009-6 0.25
100
150
150 at min.
T O U R E C H A F : S H O R I N G T O W E R W I T H I N T E G R A L S A F E T Y S Y S T E M
> SHORINGTOWER TROLLEY
Description
Code Weight
Shoring tower trolley 050103-1 20.0
>ADJUSTABLE HEAD
Description
Code Weight
Adjustable head 011153-4 9.1
4 way head
050100-7 3.5
Head adjuster
050120-5 8.5
Wide adjustable head 192460-4 11.2
T1 short adjustable head 024628-0 7.2
17.3
8.9
27
8.2
98.2
58 cm
adjustment
Suitable for 1m and
1.50 frames.
