We recommend allowing 25 cm between
bins and cradles to make it easier to access
the lifting rings when lifting by crane.
Transport
and
lifting
...
TOURECHAF
T O U R E C H A F : S H O R I N G T O W E R W I T H I N T E G R A L S A F E T Y S Y S T E M
Ensure that the loading zone is safe
to make handling easier...
2 full storage bins
3 empty storage bins.
A 20 x 1.50 m
frame cradle
loaded on a full
storage bin
2 x 20 frame
cradles full
6 empty 20 frame
cradles
2 x 13 access
platform cradles full
6 empty 13 access
platform cradles
Typical loading
> Maximum number of bins and cradles stacked during lifting:
>Transport:
25
25
25
25
25
25
25
25
NB:
The equipment must be firmly
lashed to prevent any risk of de
moving during transport.
NB:
Comply with the general
handling rules.
