30 / 32
30
Components
...
150
100
100
150
100
100
100
100
> FRAMES
Dimensions
Code Weight
1.50 m
011156-7 12.4
1.00 m
011106-2 10.8
>ACCESS FRAME
Dimensions
Code Weight
1.50 m
011157-5 11.5
1.00 m
011107-0 8.4
> M
AIN COMPONENTS
:
> A
DDITIONAL COMPONENTS
:
>ACCESS PLATFORM
Dimensions
Code Weight
1.00 m
011104-7 11.3
1.50 m
011154-2 14.8
90.6
Course
adjustment
Fine adjustment
Swivel
base plate
70
100 - 150
49 cm
adjustment
> SCREW JACK
Description
Code Weight
Screw jack
011155-9 9.2
35 to 300
100 - 150
50 - 100
> BASIC STANDARD
Dimensions
Code Weight
0.50 m
011170-8 2.8
1.00 m
011171-6 5.1
* These ledgers are not suitable for
supporting decks.
> LEDGER
Dimensions
Code Weight
0.15 m *
250201-1 0.9
0.35 m *
250203-7 1.5
0.70 m
250207-8 2.5
2.00 m
250220-1 6.0
2.50 m
250225-0 7.5
3.00 m
250230-0 9.6
> LEDGER
Dimensions
Code Weight
1.00 m
250210-2 3.3
1.50 m
250215-1 4.6
T O U R E C H A F : S H O R I N G T O W E R W I T H I N T E G R A L S A F E T Y S Y S T E M
102.5
12.5
17.3
8.9
> 2WAYADJUSTABLE HEAD
Description
Code Weight
2 way adjustable head
011100-5
9.0
Travel
60 cm
100
> SAFE ERECTION GUARDRAIL
Dimensions
Code Weight
0.70 m
256070-4 5.9
1.00 m
256100-9 6.3
1.50 m
256150-4 10.1
2.00 m
256200-7 11.4
2.50 m
256250-2 13.2
3.00 m
256300-5 15.0
100 - 200
> STANDARD
Dimensions
Code Weight
1.00 m
250101-3 5.3
2.00 m
250102-1 9.6
0.15 m
ledger
TOURECHAF
Unless otherwise stated all dimensions are
in cm.Weights are in kg.
Dim. 48.3
