>Technical characteristics
of the main components:
> Stability:
The tower must be stabilised against
wind loads, in particular during as-
sembly and dismantling.
For normal wind conditions, it is advisable
to limit the height of the tower to 3.5
times the smaller dimension of the base
(3 times for a mobile scaffold).
For strong wind conditions, the towers
should not be isolated but should be
connected together or anchored to
stabilise them in all directions.
Description
Geometry
Rp
Frame
- Standard Tube Ø 60.3 x 2.7 mm 320 MPa
- Ledger
Tube Ø 40 x 2 mm 235 MPa
Ledger
Tube Ø 48.3 -x 2.7 mm 320 MPa
Screw jack Tube Ø 48 x 5.6 threaded 320 MPa
Adjustable head Tube Ø 48 x 5.6 threaded 320 MPa
Diagonal brace Tube Ø 38 -x-2.7 mm 320 MPa
T
he maximum load is
6 tonnes
per standard for towers less
than
6 m
high. Specific calculations
for strength and stability need to be
made for higher towers.
TOURECHAF
> Dimensions:
Standard Tourechaf with 2 way
adjustable heads and screw jacks
100
100
(237 to 346)
15 min to
64 max.
22 min to
82 max.
22 min to
82 max.
25.2 min.to
45.7 max.
24.3 50
(96.3 to 156.3)
22 min to
82 max.
24.3
100
146.3 min to
206.3 max.
25.2 min. to
45.7 max.
24.3
49.5 to 0.70
100
With one frame:
Height from
1.82 m to 2.46 m.
Minimum height determined by the
length of the screw jacks and heads.
140.3 to 209.8
T O U R E C H A F : S H O R I N G T O W E R W I T H I N T E G R A L S A F E T Y S Y S T E M
Isolated tower
Towers in blocks
15 min. to
64 max.
NB:
See general recommendations
pages 28 and 29.
h < 3.5
l
h < 3.5
l
l
l
L
l
H < 3 L
> LowTourechaf tower:
Standard Tourechaf with T1
MillsTour adjustable head and
screw jacks:
Tourechaf with 2 way adjustable
heads and fixed feet
Tower with 1.50 m standards and
diagonal braces.
Height from
0.96 m to 1.56 m.
Standard Tourechaf with 2 way
adjustable heads and fixed feet
Height from
1.46 m to 2.06 m.
Tourechaf withT1 MillsTour
adjustable heads and fixed feet
Height from
0.49 m to 0.70 m.
NB:
The middle standards must
be braced using ledgers
and diagonal braces at all levels.
Height from
1.40 m to 2.09 m.
